SOM 8550 (Under development)
Applications
- a wide range of performance heavy IoT applications including autonomous mobile robots, industrial drones, camera, edge AI box, video collaboration, video transcoding, and cloud gaming.
Specification
| Processors | Qualcomm® QCS8550 Octa-core [email protected] + [email protected] + [email protected] |
| Memory/Storage | LPDDR5/5X, 8GB/12GB/16GB UFS 3.1/4.0, 128/256GB (Optional) |
| Wireless | Qualcomm® Wi-Fi 802.11 be, Bluetooth 5.3 (WCN7851) |
| Video | Codec up to 4K240/8K60 decode, 4K120/8K30 encode. Concurrent 4K60 en/decode |
| Graphics | Adreno 740, Ray tracing, OpenGL ES 3.2, Vulkan 1.2, OpenCL 3.0 full profile, Adreno NN direct | Power Management | Qualcomm® Quick Charge™ 5 technology (PM8550, PMK8550, PM8550B/BH/BHS, PM8550VE/VS, PM8010 × 2, PMR735D) |
| Display | Two 4-lane DSI D-PHY 1.2 or two 3-trio C-PHY v1.1 with VESA DSC v1.1. DisplayPort v1.4 at 8.1 Gbps/lane over Type-C with support for MST and VESA DSC v1.1 |
| Camera | Six combo-PHYs with four lanes for D-PHY/three trios for C-PHY each, two combo-PHYs (CSI6 and CSI7) with two lanes for D-PHY/one trio for C-PHY each, D-PHY v1.2: 2.5 Gbps/lane, C-PHY v2.0: 13.68 Gbps/trio |
| USB | USB 3.1 (Type-C) |
| Bluetooth | Bluetooth 5.1 |
| Package | LGA |
| OS support | AndroidTM 13 or later |
| TOPS | 48 INT8 TOPS, 12 FP16 TOPs |
| Size | 54x45(mm) |
